Tình trạng: Còn hàng
Mã sản phẩm: 2257
Đơn vị tính: Cái
Thương hiệu: Amphenol
Bảo hành: 12 tháng
Giá bán: Liên hệ
Số lượng:
| Part Number: | MS3112E12-8P | |
| Product Type: | MIL-DTL-26482 series 1 Mil-Spec Circular Connector | |
| Series: | MS3112 Box Mounting Receptacle | |
| Connector Type: | Receptacle | |
| Orientation: | Straight | |
| Contact Type: | Pin Contacts | |
| Number of Contacts: | 8 Contacts | |
| Contact Termination: | Solder Cup | |
| Shell sizes: | 12 | |
| Contact Arrangement: | 12-8 | |
| Coupling Method: | Bayonet | |
| Mount Method: | Panel Mount | |
| Mount Feature: | 4-Hole Flange | |
| Wire Gauge: | 20/22/24AWG | |
| Durability: | 500 cycles | |
| Alternate Position: | N – Normal | |
| Shielding performance: | Unshielded | |
| Temperature range: | -55°C to + 125°C | |
| Protection degree: | IP67 |
